• Socket A for AMD Athlon™ XP processor up to 333/266 MHz FSB
• Support the AMD Sempron™ Processor
Click here to download the BIOS update

Chipset

• SiS 741GX/963L Chipset
• Embedded Real256E 3D Graphics with 64M share memory
• Audio – AC’97 Codec
• Realtek 8201B 10/100Mbps Fast Ethernet PHY

System BIOS

• AMI 2Mb Flash ROM
• Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Full support for ACPI revision 1.0 specification

Memory

• 2 x 184-pin DIMM sockets support two 2.5V DDR SDRAMs (DDR333/266)
• Maximum memory : 2 GB

Expansion Slots

• 1 x AGP 8X, 2 x PCI, 1 x CNR
I/O Interface



Back Panel I/O Ports
• PS/2 keyboard and mouse connectors
• One Parallel Port
• One Serial Port
• One VGA port
• Four USB 2.0 Ports
• One RJ 45 Port
• Audio I/O (Line-in, Line-out and Mic-in)

IDE: Two Ultra DMA 133/100/66

Onboard ports, headers and others
• 20-pin ATX power supply connector
• 4-pin ATX 12V Power Supply connector
• One USB header support additional 2 USB2.0 ports
• One Front panel switch/LED header
• One Front panel audio header
• CPU / SYS FAN headers
• One IrDA for SIR header
• One Speaker header
• One CD in header

Form Factor & Layers

• Micro ATX Form Factor, 244*200 mm
