- AMD Athlon™ 64 / Sempron™ processors, Socket 754
- 1600 MT/s HyperTransport™
- DDR400 / DDR333 / DDR 266 DRAM x2 DIMMs, Max 2GB
- Integrated Ultra256 2D/3D Graphics
- AGP 8X slot (1.5v only)
- 2 Serial ATA w/ RAID 0, RAID 1 & JBOD
- 5.1 channel Audio (ADI)
- 10 / 100 Mbps LAN (Realtek)
- 8 USB 2.0 ports
 |
- AMD Athlon™ 64 / Sempron™ processors, Socket 754
- 1600 MT/s HyperTransport™
- DDR400 / DDR333 / DDR 266 DRAM x2 DIMMs, Max 2GB
- Integrated Ultra256 2D/3D Graphics
- AGP 8X slot (1.5v only)
- 2 Serial ATA w/ RAID 0, RAID 1 & JBOD
- 5.1 channel Audio (ADI)
- 10 / 100 Mbps LAN (Realtek)
- 8 USB 2.0 ports
|
|
|
|
 |
| Processor: |
Socket 754 for AMD Athlon™ 64 / Sempron™ processors |
| Chipset: |
SiS 760GX + SiS 964 – MuTIOL® 1GB/s bandwidth HyperStreaming™ Engine (HSE) |
| Front Side Bus: |
Up to 1600MT/s HyperTransport™ |
| Memory: |
2 x 184-pin DIMM sockets up to 2GB DDR400/333/266 DDR DRAM |
| VGA on Die: |
Integrated Ultra256 2D/3D Graphics |
| Expansion Slots: |
1 AGP slot supports 8X / 4X modes and 3 PCI slots |
| IDE: |
2 UltraDMA 133 - supports up to 4 devices |
| Serial ATA(SATA)/RAID: |
Supports 2 Serial ATA devices, RAID 0, RAID 1, JBOD |
| Audio: |
ADI AD1888; 5.1 channel audio |
| LAN: |
RTL8201BL; 10/100 PHY |
| IEEE1394: |
N/A |
| Back Panel I/O Ports: |
1 x PS/2 mouse
1 x line-in / line-out / MIC ports
1 x PS/2 keyboard
1 x parallel
1 x RJ45
1 x COM1 port
4 x USB 2.0
1x VGA port
|
| Internal I/O Connectors: |
2 x USB 2.0 headers support 4 ports
1 x S/PDIF header out
1 x COM2 header
|
| BIOS Features: |
4Mb flash ROM w/ LAN Boot, PnP, DMI 2.0, WfM 2.0, SMBIOS 2.3, ACPI 1.0b |
| Support CD: |
Chipset Drivers, DirectX 9.0, RAID Driver, VGA Driver, USB 2.0 Driver, Audio Driver, Network Driver, Adobe Reader 6.0, SuperUtilities, Norton Internet Security, Motherboard Support CD |
| Standards/Manageability: |
PCI 2.3, USB2.0, WfM 2.0, DMI 2.0, WOL by PME, LPC 1.1 Interface, PC2001 |
| Special Features: |
Wake on ring, LAN, USB, keyboard & mouse, STR (Suspend-to-Ram), STD (Suspend-to-Disk), SuperRecovery, SuperBoot, SuperBIOS-Protect, SuperSpeed by BIOS, SuperStep, SuperLogo, SuperUpdate by CD Driver |
| Form Factor: |
Micro ATX (9.6” x 8.6”) |
|
